Place of Origin:
China
Brand Name:
CHENGUANG FSP
Model Number:
PA-600
Contact Us
Active Chlorine Grade ACM Rubber
DESCRIPTION
In 2019, the Global Acrylic Rubber Market was valued at USD 750 million and is projected to exceed USD 1.2 billion in 2024, with a CAGR of approximately 8.2% from 2019 to 2024. Acrylic rubber, which is also referred to as ACM (alkyl acrylate copolymer) or Hy Temp, is a specialty rubber known for its high resistance to heat, aging, oil, ozone, ultraviolet radiation, and more. This makes it a popular choice for automotive transmissions, hoses, gaskets, adhesives, beltings, and O-rings. Additionally, acrylic rubber has dampening properties, which make it suitable for use in dampening mounts.
TEMPERATURE RANGE
Low Temp: -20°C (-5°F) Brittle: -25°C (-13°F)
High Temp: 150°C (300°F) Intermittent: 180°C (356°F)
PARAMETERS
ACM Rubber Physical Properties
|
||||||||
---|---|---|---|---|---|---|---|---|
Grade | Density | Moony | Tensile Strength | Elongtation | Compression Set | Tg | Application | Product Feature |
g/cm3
|
ML1+4 @ 100℃
|
Mpa |
%
|
%, ASTM D395
Method B
150℃*70hr
|
℃
|
|||
Carboxylic Grade
|
||||||||
PA-515HE
|
1.10
|
50 | 16.60 | 220 | 18 |
-18 |
Gasket,Oil seal,O-ring
|
High strength,low compression, excellent
High temperature resistance(180℃)
|
PA-515E | 1.10 | 40 | 13.60 | 190 | 20 | -23 |
Hose,Gasket,Oil seal,Oring
|
Good for adhesion,good mold low,low compression,excellent high temperature resistance(180℃)
|
CLASSIFICATION
APPLICATIONS
The market growth is being propelled by the increasing production of automobiles and the need for durable products. Acrylic rubber is predominantly used for automotive seals and gaskets due to the escalating demand for oil-resistant rubber materials. Additionally, the market is positively impacted by the need for lower fuel consumption and the increasing temperatures in the engine compartment. The market will continue to expand steadily as end-users, such as customer merchandise and plastics, create a greater demand for acrylic rubber. Rapid industrialization, particularly in emerging economies such as China, will also play a crucial role in the market's growth in the coming years.
