Place of Origin:
China
Brand Name:
CHENGUANG FSP
Certification:
ISO
Model Number:
7170
Contact Us
General Purpose Silicone Rubber for Molding
DESCRIPTION
FEATURES
This product adopts high quality raw materials and special ingredients, which makes it own the following properties: excellent high and low temperature resistance. This rubber has very good transparency and physical, mechanical properties. The molded silicone rubber use vulcanizator “Double 2, 5”. It is suitable for making common keypads silicone rubber products and accessories, especially for colored rubber products and molding process.
TYPICAL PROPERTIES
| Item | Unit | Test Data | |
| DHS-7150 | DHS-7170 | ||
| Density | g/cm3 | 1.15+/-0.05 | 1.21+/-0.05 |
| Hardness | Shore A | 50+/-3 | 70+/-3 |
| Tensile Strength | Mpa | ≥8.0 | ≥7.5 |
| Elongation at Break | % | ≥380 | ≥260 |
| Tensile Set | % | ≤8 | ≤7 |
| Tear Strength | KN/m | ≥18.7 | ≥17.5 |
* first vulcanization condition for test piece: 175℃×5min
* Further safety and handing guide, can follow the product’s Material Safety Data Sheet or consult us!
Packed by plastic bags and hardened carton, 20kgs net in a carton.
APPLICATION
1. Electronic devices such as keypads, connectors, and seals.
2. Medical equipment such as tubing, valves, and gaskets.
3. Kitchenware such as baking molds, utensils, and grips.
4. Automotive components such as gaskets, seals, and hoses.
5. Toys such as action figures, dolls, and playsets.
