500% Elongation 6Mpa Injection Molding Elastomer Silicone Liquid Silicone Rubber

Injection Molding Liquid Silicone Rubber (LSR) is a specialized silicone rubber that is specifically formulated for injection molding processes. It is a versatile material that can be shaped into intricate and complex parts with high precision and accuracy. During the injection molding process, LSR is injected into a mold cavity under high pressure, where it takes the shape of the mold and sets into a solid material. LSR boasts excellent mechanical properties such as high elongation, resistance to tearing, and compression set resistance, making it an ideal material for applications that require durability, flexibility, and heat resistance. Injection molding LSR is a cost-effective and efficient production process that offers high production rates, short cycle times, and low waste. LSR's unique properties make it suitable for various applications, including medical devices, automotive components, consumer goods, and electronics, among others.

The vulcanization can be heat accelerated. The curing time depends on mold size.
The necessary time of thermal conduction should be fully counted in case of the mold size is big enough. The cooling and demold time also depend on the article size and the curing temperature.

PACKING & SHIPPING

The product is supplied in 2×20Kg plastic drum, net weight.
The product has a shelf life of 6 months at least if stored in the sealed original container between 0℃ to 30℃.
Storage time beyond the specified data does not mean that the product is no longer usable. In which case, the properties, required for the intended use must be checked for quality assurance reasons.
There is no shipping limitation.


COMPATIBILITY

Certain materials, chemicals, curing agents and plasticizers can inhibit the cure of rubber. Most notable of these include:

• Organotin and other organometallic compounds
• Silicone rubber containing organotin catalyst
• Sulfur, polysulfides, polysulfones or other sulfur-containing materials
• Amines, urethanes or amine-containing materials
• Unsaturated hydrocarbon plasticizers
• Some solder flux residues

If a substrate or material is questionable with respect to potentially causing inhibition of cure, it is recommended that a small scale compatibility test be run to ascertain suitability in a given application. The presence of liquid or uncured product at the interface between the questionable substrate and the cured gel indicates incompatibility and inhibition of cure.

ATTENTION

As components of group A and group B have been confirmed without toxic and aggressive substances over past years, no
need special preventive measure, only requests to use the general industrial health standard.
It should avoid contacting with nitrogen, phosphorus, sulfur compound and organic tin or other heavy metal compound because of being easy to be inactivated. The containers should be keeping clean.
Temperature will impact pot life of mixed rubber, the higher temperature, the shorter pot life.

LMITED WARRANTY INFORMATION

The data presented in this leaflet are in accordance with the present state of our knowledge, but do not absolve the user from carefully checking all supplies immediately on receipt. We reserve the right to alter product constants within the scope of technical progress or new developments. The recommendations made in this leaflet should be checked by preliminary trials because of conditions during processing over which we have no control, especially where other companies’ raw materials are also being used. The recommendations do not absolve the user from the obligation of investigating the possibility of infringement of third parties’ right and, if necessary, clarifying the position, recommendations for use do not constitute a warranty, either express or implied, of the fitness or suitability of the products for a particular purpose.
