Place of Origin:
China
Brand Name:
CHENGUANG FSP
Certification:
ISO9001 / FDA
Model Number:
7270E
Contact Us
LSR Common Silicone Rubber for Molding and Extrusion
Tasteless and Odorless 14% Compression Set LSR Common Silicone Elastomer Rubber
DESCRIPTION
LSR's exceptional properties are attributed to its siloxane bond, which provides an inorganic backbone that does not react with biological materials and can be combined with organic chemical groups. This bond also enhances mechanical performance and strength.
The inorganic nature of LSR makes it ideal for medical and skin-contact applications, while its ability to blend with other chemical groups allows it to achieve exceptional performance. For example, LSR's rebound resilience, which refers to its ability to transfer energy after a force is applied, surpasses that of many other elastomers and is highly preferred for pumping applications.
The injection molding process of liquid silicone rubber provides ease of processing, high-volume production, consistent part quality, and enhanced productivity. Due to its remarkable properties, LSR has become the preferred material for demanding applications.
PROPERTIES
| Item | Unit | Test Data | |
|
DHS-7270E |
DHS-7260E |
||
|
Appearance |
Milky-white no obvious extraneous matter |
||
| Density | g/cm3 |
1.21±0.05 |
1.18±0.05 |
| Hardness | Shore A |
70±3 |
60±3 |
| Tensile Strength | Mpa | ≥7.0 | ≥7.5 |
| Elongation at Break | % | ≥250 | ≥360 |
| Tension Set | % | ≤14 | ≤14 |
| Tear Strength | KN/m | ≥20 | ≥20 |
Physical and Mechanical Properties are based on first vulcanization data
First vulcanization condition for test piece: 175℃×5min
Second vulcanization condition for test piece: 200℃×2h
Vulcanizator: 80% DMDBH,quantity added 0.65% *
PROPERTIES
1. In terms of temperature endurance, molded silicone surpasses other elastomers, with the ability to withstand a broad range of high and low temperatures. It remains stable in temperatures ranging from minus 60 degrees Celsius to 180 degrees Celsius.
2. Liquid silicone rubber boasts exceptional mechanical properties, including good elongation, high tear and tensile strength, excellent flexibility, and a hardness range typically between 5 to 80 Shore A.
3. LSR also offers excellent electrical insulating properties, making it advantageous for various electrical applications. In comparison to conventional insulating materials, silicone can function in far higher and lower temperatures.
4. LSR is inherently translucent, with a natural white color that can be easily pigmented to produce custom, molded products in various colors.
APPLICATIONS
1. Automotive Industry: LSR Common Silicone Rubber is widely used in the automotive industry for molding and extrusion applications such as seals, gaskets, and hoses, due to its excellent temperature and chemical resistance properties.
2. Medical Industry: It is used in the medical industry for molding and extrusion applications such as catheters, medical tubing, and other medical devices, due to its biocompatibility and excellent sterilization properties.
3. Electronics Industry: LSR Common Silicone Rubber is used in the electronics industry for molding and extrusion applications such as keypads, connectors, and insulators, due to its excellent electrical insulation properties.
4. Industrial Manufacturing: The material is used in various industrial manufacturing applications for molding and extrusion of products such as O-rings, grommets, and other seals, due to its durability and chemical resistance properties.
ABOUT US
Our company is committed to the research and development of new materials, with a plant capacity exceeding 5000t/y and 15 sets of banbury production lines. Our primary objective is to create innovative solutions that meet the requirements of our domestic and international customers. We work closely with universities, professional rubber research institutes, and customers to ensure that our products meet market demands. Our laboratory has earned CNAS certification, the most reliable certification for quality control. We adhere to strict quality control standards based on IATF 16949:2016, GB/T 28001-2011, and GB/24001-2004. Our products are widely used in various industries, including chemistry, aviation, airspace, electronics, petroleum, automobile, textile, and machinery. We have a well-established customer base in Europe, America, the Middle East, and Southeast Asia.
FAQ
1. Does LSR Common Silicone Rubber require any special storage conditions?
Yes, LSR Common Silicone Rubber should be stored in a cool and dry place away from direct sunlight and heat sources. It should also be kept away from any sources of moisture as it can cause degradation of the material.
2. Can LSR Common Silicone Rubber be used for medical implants?
Yes, LSR Common Silicone Rubber is used in medical implants due to its biocompatibility and suitability for sterilization.
3. What is the maximum temperature that LSR Common Silicone Rubber can withstand?
LSR Common Silicone Rubber can withstand temperatures ranging from as low as -50°C to as high as 200°C.
4. Is LSR Common Silicone Rubber suitable for high-pressure applications?
Yes, LSR Common Silicone Rubber can withstand high-pressure applications due to its excellent compression set resistance and durability.
