Place of Origin:
China
Brand Name:
CHENGUANG FSP
Certification:
ISO9001 / FDA
Model Number:
7280E
Contact Us
LSR Common Silicone Rubber for Molding and Extrusion
DESCRIPTION
LSR's exceptional properties are attributed to its siloxane bond, which provides an inorganic backbone that does not react with biological materials and can be combined with organic chemical groups. This bond also enhances mechanical performance and strength.
The inorganic nature of LSR makes it ideal for medical and skin-contact applications, while its ability to blend with other chemical groups allows it to achieve exceptional performance. For example, LSR's rebound resilience, which refers to its ability to transfer energy after a force is applied, surpasses that of many other elastomers and is highly preferred for pumping applications.
The injection molding process of liquid silicone rubber provides ease of processing, high-volume production, consistent part quality, and enhanced productivity. Due to its remarkable properties, LSR has become the preferred material for demanding applications.
PROPERTIES
| Item | Unit | Test Data | |
|
DHS-7270E |
DHS-7280E |
||
|
Appearance |
Milky-white no obvious extraneous matter |
||
| Density | g/cm3 |
1.21±0.05 |
1.25±0.05 |
| Hardness | Shore A |
70±3 |
80±3 |
| Tensile Strength | Mpa | ≥7.0 | ≥6.5 |
| Elongation at Break | % | ≥250 | ≥150 |
| Tension Set | % | ≤14 | ≤15 |
| Tear Strength | KN/m | ≥20 | ≥18 |
Physical and Mechanical Properties are based on first vulcanization data
First vulcanization condition for test piece: 175℃×5min
Second vulcanization condition for test piece: 200℃×2h
Vulcanizator: 80% DMDBH,quantity added 0.65% *
PROPERTIES
1. In terms of temperature endurance, molded silicone surpasses other elastomers, with the ability to withstand a broad range of high and low temperatures. It remains stable in temperatures ranging from minus 60 degrees Celsius to 180 degrees Celsius.
2. Liquid silicone rubber boasts exceptional mechanical properties, including good elongation, high tear and tensile strength, excellent flexibility, and a hardness range typically between 5 to 80 Shore A.
3. LSR also offers excellent electrical insulating properties, making it advantageous for various electrical applications. In comparison to conventional insulating materials, silicone can function in far higher and lower temperatures.
4. LSR is inherently translucent, with a natural white color that can be easily pigmented to produce custom, molded products in various colors.
APPLICATIONS
Food grade LSR rubber has a wide range of applications in the food industry due to its exceptional properties, including its resistance to high temperatures, low compression set, and excellent flexibility. Some additional applications of food grade LSR rubber include:
1. Sealants and gaskets: Food grade LSR rubber is used to produce seals and gaskets for food and beverage containers, ensuring that they remain airtight and free from contamination.
2. Cooking and baking utensils: Food grade LSR rubber is used to create cooking and baking utensils such as spatulas, baking mats, and cake molds, as it is heat-resistant and can withstand high temperatures.
3. Baby products: Food grade LSR rubber is used to produce baby products such as teethers, pacifiers, and bottle nipples, as it is soft, flexible, and safe for infants to chew.
4. Medical and dental applications: Food grade LSR rubber is used in medical and dental applications such as dental impression materials, medical tubing, and surgical instruments, due to its biocompatibility and resistance to high temperatures and chemicals.
5. Beverage dispensing equipment: Food grade LSR rubber is used to produce components for beverage dispensing equipment, such as O-rings and gaskets, ensuring that the equipment remains airtight and safe for use with food and beverages.
ABOUT US
As a professional manufacturer, we are dedicated to researching and developing new materials. With a plant capacity exceeding 5000t/y and 15 sets of banbury production lines, our main goal is to provide innovative solutions that meet the needs of our domestic and international customers. We collaborate closely with universities, professional rubber research institutes, and our customers to ensure that our products meet the demands of the market. Our laboratory has been awarded CNAS certification, the most reliable certification for quality control. We follow strict quality control standards based on IATF 16949:2016, GB/T 28001-2011, and GB/24001-2004. Our products are widely utilized in various industries such as chemistry, aviation, airspace, electronics, petroleum, automobile, textile, and machinery. We have a well-established customer base in Europe, America, the Middle East, and Southeast Asia.
FAQ
1. Does LSR Common Silicone Rubber require any special storage conditions?
Yes, LSR Common Silicone Rubber should be stored in a cool and dry place away from direct sunlight and heat sources. It should also be kept away from any sources of moisture as it can cause degradation of the material.
2. Can LSR Common Silicone Rubber be used for medical implants?
Yes, LSR Common Silicone Rubber is used in medical implants due to its biocompatibility and suitability for sterilization.
3. What is the maximum temperature that LSR Common Silicone Rubber can withstand?
LSR Common Silicone Rubber can withstand temperatures ranging from as low as -50°C to as high as 200°C.
4. Is LSR Common Silicone Rubber suitable for high-pressure applications?
Yes, LSR Common Silicone Rubber can withstand high-pressure applications due to its excellent compression set resistance and durability.
