General Purpose Silicone Rubber for Extrusion
Extrusion Use White 5280 General Purpose Silicone Rubber with 10% Tension Set at Break
DESCRIPTION
This product can undergo basic processing after adding the vulcanizing agent "Double 2, 4." When subjected to appropriate technical conditions, it doesn't require a second vulcanization step. The final product boasts exceptional characteristics like arc and corona resistance, high and low-temperature resistance, and electrical insulation. This makes it a perfect material for various applications, including heat-resistant seals, electrical wire and cable, electrical insulator parts, foam strips, and irregularly shaped rubber tubes.
PARAMETERS
| Model |
DH-5280
|
|
|
For Line
|
For Tube
|
|
| Appearance | milky-white, slightly transparent, no obvious extraneous matter | |
| Density (g/cm3) | 1.25±0.05 | |
| Hardness (Shore A Points) |
80±2
|
|
| Tensile Strength (MPa≥) |
7.0
|
7.0
|
| Tensile Strength at Break (% ≥) |
180
|
150
|
| Tension Set at Break (% ≤) | 10 | 10 |
| Tear Strength (kN/m ≥) |
20
|
|
| Volume Resistivity (Ω·cm, ≥) |
3.0×1014
|
|
| Dielectric Strength (kV/mm ≥) | 20 | |
Physical and Mechanical Properties are based on first vulcanization data, Electrical Properties are drawn from
second vulcanization data.
First vulcanization Condition for test piece: 175℃×5min, Second vulcanization condition for test piece:
200℃×2h.
Vulcanizator: 80% DMDBH,quantity added 0.65%.
PROPERTIES
Construction: Silicone's resilience against wind, rain, UV, and ozone, coupled with its exceptional durability, make it a formidable material for construction applications, including coatings, adhesives, and sealants.
Medical: Silicone recipes that are FDA-approved make it a safe material for a wide range of medical equipment, such as feeding tubes, respiratory masks, pacemakers, and stents.
Food packaging and processing: Silicone is a safe and durable material for food packaging and processing, much like its use in the medical industry. It is commonly found in kitchen utensils, appliances, and storage containers.
Electronics: Silicone is used in many electronic devices as sealants, coatings, and adhesives for various circuits, connectors, and tubes due to its exceptional properties.
PROCESSING FORM
The CHENGUANG FSP solid silicone rubber grades can be processed through conventional methods like injection, compression molding, transfer, and extrusion, in addition to calendering.
