High Transparency Silicone Rubber
FEATURES
High Transparency Silicone Rubber is characterized by its exceptional transparency, making it an ideal material for applications where visual clarity is important. Additionally, it also features a high elongation at break, allowing it to stretch up to 300% of its original length before breaking. Other features of this material may include good thermal stability, excellent electrical insulation properties, resistance to weathering and aging, and more, depending on the specific formulation and intended application.
SPECIFICATION
| Model |
DH-9430
|
DH-9440 | |
| Appearance |
Translucent, no obvious extraneous matter |
||
| Density (g/cm3) |
1.07±0.04 |
1.13±0.04 |
|
| Hardness (Shore A Points) |
32±2
|
40±2 |
|
| Tensile Strength (MPa≥) |
8.0
|
9.0 |
|
| Elongation at Breakage (%≥) |
700
|
600 |
|
| Tension Set (% ≤) |
8 |
8 | |
| Tear Strength (kN/m ≥) | 20 | 35 | |
|
Volume Resistivity (Ω.cm) |
1.0X1016 |
||
|
Dielectric Strength (kv/mm≧) |
22 |
||
| Linear Shrinkage Rate after the first vulcanization | 3.2%-3.7% | 3.0%-3.6% | |
Physical and Mechanical Properties are based on the first vulcanization data,Electrical Properties are drawn from the second vulcanization data.
The first vulcanization condition for test piece: 175℃×5min；The second vulcanization condition for test piece: 200℃×2h
Vulcanizator: Liquid DMDBH, quantity added 0.65%
APPLICATION
1. High Clarity: High transparency silicone rubber is known for its exceptional clarity. It allows light to pass through with minimal distortion, making it ideal for applications that require clear or transparent parts.
2. Resistance to Yellowing: Unlike other materials that may turn yellow over time, high transparency silicone rubber retains its clarity and transparency, even after prolonged exposure to sunlight or other environmental factors.
3. High Temperature Resistance: High transparency silicone rubber can withstand high temperatures without losing its transparency or physical properties. It can operate effectively in temperatures ranging from -60°C to 200°C.
4. Good Electrical Insulation Properties: High transparency silicone rubber is an excellent electrical insulator, making it ideal for electrical and electronic applications.
5. Easy to Process: High transparency silicone rubber is easy to process and mold into various shapes and sizes. It can be injection molded or extruded, and can be customized to meet specific application requirements.
