Place of Origin:
China
Brand Name:
CHENGUANG FSP
Certification:
FDA / LFGB / SGS
Model Number:
DH-9460
Contact Us
High Transparent Silicone Rubber
8 Tension Set High Transparent Silicone Rubber for Medical Applications and Devices
FEATURES
High transparent silicone rubber is a type of silicone material with exceptional optical clarity and high transparency. It is a clear and ultra-pure material that is used in a variety of applications where optical clarity is essential. High transparent silicone rubber is highly resistant to sunlight, UV rays, aging, and weathering, making it an ideal material for outdoor applications. It is also hypoallergenic, making it safe for use in medical and healthcare products. This material is widely used in industries such as electronics, automotive, medical, and aerospace, where transparency is key.
SPECIFICATION
| Model |
DH-9450
|
DH-9460 | |
| Appearance |
Translucent, no obvious extraneous matter |
||
| Density (g/cm3) |
1.15±0.04 |
1.18±0.04 |
|
| Hardness (Shore A Points) |
50±2
|
60±2 |
|
| Tensile Strength (MPa≥) |
9.0
|
9.0 |
|
| Elongation at Breakage (%≥) |
500
|
400 |
|
| Tension Set (% ≤) |
8 |
8 | |
| Tear Strength (kN/m ≥) | 40 | 40 | |
|
Volume Resistivity (Ω.cm) |
1.0X1016 |
||
|
Dielectric Strength (kv/mm≧) |
22 |
||
| Linear Shrinkage Rate after the first vulcanization |
2.9-3.4% |
2.8%-3.4% | |
Physical and Mechanical Properties are based on the first vulcanization data,Electrical Properties are drawn from the second vulcanization data.
The first vulcanization condition for test piece: 175℃×5min；The second vulcanization condition for test piece: 200℃×2h
Vulcanizator: Liquid DMDBH, quantity added 0.65%
APPLICATION
1.Lighting: The high transparency of this material makes it an ideal choice for use in LED lighting applications, where it can be used as a lens or cover to protect the LED and enhance its brightness.
2. Construction: High transparency silicone rubber can be used in construction applications such as sealants and adhesives, where its high temperature resistance and durability are important.
3. Aerospace: High transparency silicone rubber can be used in aerospace applications such as gaskets, seals, and insulation, where resistance to high temperature and pressure is essential.
4. Consumer products: High transparency silicone rubber is used in a variety of consumer products, such as phone cases, watch straps, and kitchen utensils. Its flexibility, durability, and hypoallergenic properties make it a popular choice for these applications.
FAQ
1. What is the estimated delivery time for your products?
If the products are readily available, we can deliver them within 3 business days. However, if they are not in stock, the delivery time can vary between 7 to 14 business days.
2. How do you package your products?
Our products are usually packaged in cartons with PE film, with each carton having a net weight of 20-25kg. For larger orders, we utilize pallets that can hold up to 500KG.
3. How can we determine the most suitable grade for our application?
Please get in touch with our sales team, and they will assist you in selecting the appropriate grade based on your specific physical properties and other relevant information.
