General Purpose Silicone Rubber for Extrusion
DESCRIPTION
General Purpose Silicone Rubber for Extrusion is a type of silicone elastomer that is specifically formulated to be processed through extrusion methods. This rubber is designed to have a balanced combination of physical properties, such as flexibility, durability, and heat resistance, making it suitable for a wide range of applications.
The material typically comes in a high-consistency form and requires a curing process, often through the use of a platinum or peroxide-based curing system, to achieve its final properties. Once cured, it exhibits excellent environmental resistance, maintaining its integrity against varying temperatures, UV light, and moisture.
PROPERTIES
| CG-7250 | |||
| For Line | For Tube | ||
|
Appearance |
milky-white, slightly transparent, no obvious extraneous matter | ||
| Density | g/cm3 | 1.18±0.05 | |
| Hardness | Shore A Points | 50±2 | 52±2 |
| Tensile Strength | mPa≥ | 8.0 | 8.0 |
| Tensile Strength at Break | % ≥ | 440 | 380 |
| Tension Set at Break | % ≤ | 14 | 12 |
| Tear Strength | kN/m ≥ | 20 | |
| Volume Resistivity | Ω·cm, ≥ | 3.0×1014 | |
| Dielectric Strength | kV/mm ≥ | 20 | |
Physical and Mechanical Properties are based on first vulcanization data, Electrical Properties are drawn from
second vulcanization data.
First vulcanization Condition for test piece: 175℃×5min, Second vulcanization condition for test piece:
200℃×2h.
Vulcanizator: 80% DMDBH,quantity added 0.65%.
*All Dowfluo products are manufactured at ISO9001:2000 registered
FEATURES
1. Versatility in Applications: General Purpose Silicone Rubber for Extrusion is suitable for creating a wide array of products such as seals, gaskets, tubing, and profiles. Its adaptability makes it a go-to material for various industries, including automotive, medical, construction, and consumer goods.
2. Excellent Physical Properties: This type of silicone rubber typically offers a good balance of properties, including flexibility, tensile strength, and elongation. It can withstand extreme temperatures, both hot and cold, and is resistant to UV light, ozone, and weathering, which contributes to its durability and longevity.
3.Ease of Processing: Designed for extrusion processes, General Purpose Silicone Rubber can be easily shaped and formed into continuous profiles and complex shapes. The extrusion process allows for efficient and consistent production of high-quality rubber parts.
4. Curing Systems: The rubber requires curing, often achieved through platinum-catalyzed addition cure systems or peroxide-based cure systems. The curing process cross-links the polymer chains, resulting in a material that has the desired mechanical and physical properties.
5.Compliance with Standards: Many formulations of General Purpose Silicone Rubber for Extrusion meet various industry standards and certifications, such as FDA compliance for food contact, UL ratings for flame resistance, or medical-grade specifications. This ensures that the material can be safely and effectively used in environments with strict regulatory requirements.
APPLICATIONS
1. Sealants/Adhesives: Vinyl methyl silicone gum is key in making silicone sealants and adhesives for durable, weatherproof sealing in construction, automotive, and more.
2. Mold Making: Its flexibility and non-stick nature make it perfect for creating molds for casting materials like concrete and resins.
3. Medical Devices: Due to its biocompatibility, silicone gum is used for medical devices like tubing and catheters.
4. Electrical Insulation: Silicone gums insulate and protect electronic components from environmental factors.
